NO. Sort specification unit
1. Vehicle parameter [Length×width×Height] 1660*1030*1080
2. Wheelbase (1150±20mm)
3. Front wheel track (850 mm)
4. Rear wheel track : 820 mm
5. Maximum ground clearance (140±15mm mm)
6. Seat height (780 ±15mm mm)
7. Chassis height (260 mm)
8. Handle height (1080 mm)
9. Packing size (1620*1020*860mm 42/40H)
10. Front mechanical suspension stroke (60 mm)
11. Rear mechanical suspension stroke (80 mm)
12. Minimum turning diameter (3400±500mm)
13. Steering angle <45° （in fact: 39°）
14.Side slip <5m/km
15.Load capacity (100kg)
16.Net weight (159kg)
17. Packing GW (187kg)
18. Brake type (front/rear) F/R disco brake
19. Brake operation mode (front/rear) F/ handbrake R/footbrake
20.Rim type (front/rear) 10寸/9寸
21. Tire size (front/rear) F/AT20*7-10 R/AT20*10-9/off-road tire
22.Tire pressure (front/rear) 9P.S. I
23.Transmission mode (Chain drive)
24. Engine parameters model (LC166FMM)
25. Type Single cylinder、4 strokes、air cooling
26. Factory Loncin
27. Bore diameter × stroke (65.5×66.2mm)
28. Cylinder working volume (223mL)
29. Compression ratio (9.0:1)
30.Rated power and corresponding speed
31. Maximum power and corresponding speed
12（1±5%）kW /7500（1±5%）rpm
32. Maximum torque and corresponding speed
17（1±5%）N · m /6000（1±5%）rpm
33. Minimum idling speed (1500±150 r /min)
34. minimum specific fuel consumption ≤354 g / kw.h
35. Fuel brand ≥RQ90
36. Lubrication mode /Pressure and splash hybrid lubrication
37. Lubrication mode /15W/40-SE(Summer)10W/30-SF(Winter)
38. Clutch mode Wet multi-piece
39. Starting mode electric
40. Ignition mode CDI
41. Components /Carburetor mode/ Plunge PZ30
42. Spark plug type (D8RTC)
43. Battery 12V/7HA
44. Front light type
12V18-18W
45. Technical parameters
Max speed /80km/h
46. starting performance 15S
47. brake performance ≤5.9m/30m/km/h
Front wheel ratio ≥60%
Rear wheel ratio ≤20%
Front wheel (force difference) ≥55%
Rear wheel (force difference) ≤24%
48. climbing ability 21°°
49. parking performance ≥18%
50. emission index CO(%) ≤2 HC(PPm) ≤250
51.Max noise db(A) ≤82 dB(A)
52. starting acceleration capability（S）≤15
53. passing acceleration capability（S）≤10
54. Component parameter /Oil tank capacity 9L
55.F/R suspension type /Hydraulic damping shock absorber
56. Exhaust muffler type /Barrel impedance composite muffler
57. F/R suspension length /L= 340 m m / L=390 m m
